Huilong Plastics Machinery Co., Ltd

No. 12 Defa Road, Hi-Tech Development Zone

http://www.huilongpm.com

+86 750 3866989

Description:Machine specification: 1200mm, 1350mm, 1450mm, 1700mm Effective width: maximum 1100mm, 1250mm, 1350mm, 1600mm Machine speed: 200m/min Extruding machine: HL-90 or HL-100 extruder with principle of energy dynamic equilibrium for economizing on the energy Extruding power: 37～45kw Extrusion output: maximum 200kg/h or 280kg/h Used resins: resin such as LDPE, PP, EVA, EAA, LLDPE, EMA, EMAA Coating thickness: 10～40μm Evenness of thickness: ≤±5% Unwinder diameter: maximum ф1200mm Base materials: paper(50～400g/m2), aluminum foil, CPE Rewinder diameter: maximum ф1700mm (friction winder) or ф1200mm (central winder) Sandwich unwinder diameter: maximum ф680mm or ф800mm Tension control: automatic tension control Electrical control mode: operated by MMI, extrusion thickness automatically controlled by computer, the whole machine is in linkage control state Transducer: AC digit vector control frequency convertor (import) Workshop requirement: Length 25m×Width 12m×Height 5m
